SLS 3D Printing Service
We provide SLS 3D printing service for functional nylon parts used in engineering prototypes and low-volume production.
Upload your CAD to receive a quote with lead time, inspection options, and DFM feedback.
ISO-Certified | Engineering-Grade Materials | Inspection Available
SLS 3D Printing Capabilities
Below are our standard SLS capabilities and tolerances. For critical features, please include CTQ notes in your RFQ so we can confirm feasibility and inspection requirements.
| Capabilities | Specification & Details |
|---|---|
|
Max build size |
340 × 340 × 605 mm
|
|
Layer thickness |
0.10 mm (typical) |
|
Typical tolerance |
±0.30 mm or ±0.30% (whichever is greater) |
|
Tolerance guidance by size |
≤100 mm: ±0.30 mm (typical) · 100–300 mm: ±0.30% (min ±0.30 mm) · >300 mm: quote-based; post-machining recommended for critical datums |
|
Minimum wall thickness |
0.70 mm (minimum) · 1.0–1.2 mm (recommended for stability) |
|
Minimum feature size |
0.50–0.80 mm (depends on geometry/orientation) |
|
Minimum hole diameter |
1.5–2.0 mm (recommended); smaller holes can be drilled post-print |
|
Recommended clearance (mating parts) |
0.30–0.50 mm for slip fits · 0.50–0.70 mm for larger parts |
|
Surface finish (standard) |
Bead blasted; matte texture (typical Ra ~10–12 μm) |
|
Supported materials |
PA12 (Nylon 12), PA11 (Nylon 11), Glass-filled nylon (PA12-GF) |
|
Finishing options |
Bead blasting (standard), dyeing, vapor smoothing, painting/coating, secondary machining |
|
Post-machining |
Drilling / reaming / tapping available for critical interfaces |
|
Threaded inserts |
Heat-set / press-fit inserts available on request |
|
Typical lead time |
Prototypes: 3–7 business days · Low-volume: 1–2 weeks (depends on quantity/finishing/inspection) |
|
Standard quality control |
Visual inspection + basic dimensional checks on key features |
|
Inspection options |
Dimensional report on request · CMM or 3D scanning available for critical geometry |
|
Documentation |
Material certificate and inspection documentation available upon request |
|
Quote checklist |
CAD (STEP/IGES) + quantity + material + tolerance/CTQ notes + finishing + inspection requirements |
Surface Finishing for SLS Parts
Standard Bead Blasting
- Removes loose powder and evens surface texture.
- Default finish for most functional SLS parts.
- No additional finishing required for internal or non-cosmetic components.
Vapor Smoothing
- Reduces surface roughness and seals surface porosity.
- Recommended for visible housings or parts exposed to moisture.
- Not required for internal components or fixtures.
Media Tumbling
- Improves surface uniformity on small or complex parts.
- Used when a smoother touch feel is required.
- Limited impact on tight dimensional features.
Color Dyeing & Coatings
- Adds color and improves surface appearance.
- Used for branded housings or visual prototypes.
- Cosmetic only; does not significantly change mechanical performance.
Specialty Finishes
- Secondary processes such as priming, conductive coatings, or inserts.
- Applied based on application and assembly requirements.
- Feasibility and impact on tolerances are evaluated during quoting.
